SKADOO S80L  Thermal Barcode Lable Printer

Check this barcode printer model specification below

Specification:

Resolution                                                          203dpi

Printing Method                                              Direct Thermal

Printing Speed                                                  127mm/s

Printing Width                                                  79mm

Max Printing Width                                        104mm

Max Printing Length                                       250mm

Interface                                                             U、USE、BU、WU、USEB、WUSE

Commands                                                         TSPL/CPCL/ZPL

Ribbon Length                                                  NA

Ribbon Width                                                   NA

Media:

Max Media Roll OD                                        NA

Min Media Roll ID                                           NA

Media Paper Type                                           Continuous, gap, fan hold, black mark

Media Rolling Up Method                           Printing side outward Rolling

Media Width                                                     Min: 26.7mm, Max 112mm

Media Height                                                    Min: 30mm, Max 300mm

Media Roll Core Size                                      NA

Media Gap                                                         Min.2mm

Media Thickness                                              0.058-0.305 mm

Label Length                                                      NA

Accessories                                                        External Media Holder (Optional)

Character Font:

Character Set                                                     GB18030 (Simplified Chinese)

Print Font                                                            ASCII Font A: 12*24 , ASCII Font B: 9*24, Chinese: 24*24

Power                                                                   DC 24V，2.5A

Paper Out Detection                                      Support

Paper Loading                                                   Easy paper loading

Barcodes:

Barcode Type                                                Code 39、39C、I25、Code 93、ITF25、EAN128、Code 128、 Codabar、 EAN-8、EAN8+2、EAN8+5、 EAN-13、EAN13+2、EAN13+5、 UPC-A、UPCA+2、UPCA+5、 UPC-E、UPCE+2、UPCE+5 MSIC、ITF14、EAN14、CODE11、POST

                                                                         QRCODE、PDF417(Optional)

Environment:

Working Environment                                   temperature: 0~45℃

                                                                                humidity: 20-90%

Storage Environment                                     temperature: -10~60℃

                                                                                humidity: 10-90%（paper exclused）

Physical:

Printer Dimension (LxWxH)                       217mm×182mm×172mm

Weight                                                                 1.375kg
